Marsh Bellofram J7646P 0-60 PSI Gauge 2-1/2 Liquid Filled

Product Description

The MARSH BELLOFRAM J7646P severe service liquid filled gauge is designed for rugged and harsh environments, especially where pulsation or vibration is present. This gauge offers a cushioning and dampening effect, reducing pointer flutter and lubricating the internals. It features a 2-1/2 IN dial and measures from 0-60 PSI.

• Liquid filled for cushioning and dampening
• Reduces pointer flutter
• Designed for rugged and harsh environments

Product Highlights

This gauge is ideal for providing reliable pressure measurements in demanding industrial and OEM environments.

Product Information

Standard Information

• Brand: MARSH BELLOFRAM
• Manufacturer Part Number: J7646P
• Country of Origin: China

Technical Specifications

• Dial Size: 2-1/2 IN
• Measuring Range: 0 - 60 PSI
• Units Of Measure: PSI, KPA
• Connection: 1/4 IN NPT Lower
• Accuracy: Plus/Minus 3-2-3% (ASME Grade B)
• Dial Face: Black Markings On White
• Case Material: 304 Stainless Steel
• Lens Material: Polycarbonate
• Pointer Material: Black Aluminum
• Movement Material: Brass
• Tube Material: Copper Alloy
• Socket Material: Copper Alloy
• Filling: Glycerin Filled
• Item Name: Severe Service Pressure Gauge
• Length: 2.68 IN
• Width: 2.68 IN
• Manufacturer: MARSH
• Series: Severe Service Series
• Model: J7646P
• Stock #: 11011
• Case Type: Plain
• Primary Range: 0-60 psi
• Secondary Scale: kPa
• Gauge Type: Pressure
• Connection Location: Bottom
• Connection Size: 1/4" NPT
• Lens Type: Polycarbonate
• Dry or Filled: Glycerin
• Wetted Parts: Copper
• Brand: INDUSTRIAL MRO
• MPN: mros3002641-J7646P
• UPC: Does not apply
