Marsh Bellofram J5458 2-1/2 0-300 PSI 1/4 BM Dry Pressure Gauge

Product Description

The Marsh Bellofram J5458 general service steel case gauge is a cost-effective, general purpose instrument designed for reliable pressure measurements. Suitable for use with water, oil, air, gas or other noncorrosive media from vacuum/compound through 5000 PSI. It features a 2-1/2 IN dial and measures from 0 - 300 PSI.

• Cost-effective
• General purpose
• Reliable pressure measurements

Product Highlights

This pressure gauge is designed for reliable pressure measurements with noncorrosive media.

Product Information

Standard Information

• Brand: MARSH BELLOFRAM
• Manufacturer Part Number: J5458
• Country of Origin: USA

Technical Specifications

• Dial Size: 2-1/2 IN
• Measuring Range: 0 - 300 PSI
• Units Of Measure: PSI, KPA
• Connection: 1/4 IN NPT Center Back
• Accuracy: Plus/Minus 3-2-3% (ASME Grade B)
• Graduations: 5 Smallest, 50 Largest
• Dial Face: Black Markings On White
• Case Material: Black Steel
• Lens Material: Acrylic Twist-In Clearlok
• Pointer Material: Black Aluminum
• Movement Material: Brass
• Tube Material: Copper Alloy
• Socket Material: Copper Alloy
• Length: 2.73 IN
• Width: 2.73 IN
• Depth: 1.23 IN
• Filled With: Dry
• SCALE INSCRIPTION/BACKGROUND COLOR: BLACK MARKINGS ON WHITE BACKGROUND
• SCALE TYPE: SINGLE
• ADJUSTABILITY: ADJUSTABLE
• SCALE NAME: PRESSURE
• DESIGN CONTROL REFERENCE: J5458
• OVERALL DEPTH: 1.188 INCHES NOMINAL
• ACTUATION TYPE: BOURDON TUBE
• GRADUATION UNIT: 50.0 POUNDS PER SQUARE INCH
• ACTUATING ELEMENT MATERIAL: COPPER ALLOY
• POINTER TYPE: INDICATING
• BEZEL TYPE: SLIPS-ON
• SURFACE TREATMENT: ENAMEL, BLACK
• SCALE RANGE: 0.0 TO 300.0 POUNDS PRESSURE PER SQUARE INCH
• SCALE SMALLEST INCREMENT: 10.0 POUNDS PER SQUARE INCH
• CONNECTOR TYPE VENT: NOT PROVIDED
• MANUFACTURERS CODE: 01170
• PROTECTIVE CRYSTAL MATERIAL: GLASS
• CONNECTION TYPE: EXTERNAL
• CONNECTION QUANTITY: 1
• CASE SURFACE TREATMENT: ENAMEL, BLACK
• SCALE ACCURACY: PORM 2 PCT MIDDLE HALF,PORM 3 PCT REMAINDER
• OVERALL DIAMETER: 2.750 INCHES NOMINAL
• MATERIAL: STEEL, DRAWN
• CONNECTION LOCATION: BACK, CENTER
• MOUNTING CONNECTION LOCATION: BACK, CENTER
• POINTER COLOR: BLACK
