Marsh Bellofram J4674 0-1500 PSI Gauge Dry 2-1/2 1/4 Lm

Product Description

The Marsh Bellofram J4674 general service steel case gauge is designed for reliable pressure measurements. Suitable for use with water, oil, air, gas or other noncorrosive media from vacuum/compound through 5000 PSI. It features a 2-1/2 IN dial and measures from 0 - 1500 PSI with an accuracy of Plus/Minus 3-2-3% (ASME Grade B).

• Cost-effective
• General purpose
• Reliable pressure measurements

Product Highlights

This gauge is suitable for use with water, oil, air, gas or other noncorrosive media.

Product Information

Standard Information

• Brand: MARSH BELLOFRAM
• Manufacturer Part Number: J4674

Technical Specifications

• Dial Size: 2-1/2 IN
• Measuring Range: 0 - 1500 PSI
• Units Of Measure: PSI, KPA
• Connection: 1/4 IN NPT Lower
• Accuracy: Plus/Minus 3-2-3% (ASME Grade B)
• Dial Face: Black Markings On White
• Case Material: Black Steel
• Lens Material: Acrylic Twist-In Clearlok
• Pointer Material: Black Aluminum
• Movement Material: Brass
• Tube Material: Copper Alloy
• Socket Material: Copper Alloy
• Length: 2.73 IN
• Width: 2.73 IN
• Depth: 1.22 IN
• Filled With: Dry
