Marsh Bellofram J4652 General Service Gauge 0-160 PSI 2-1/2 Inch

Product Description

The Marsh Bellofram J4652 general service steel case gauge is designed for reliable pressure measurements. Suitable for use with water, oil, air, gas or other noncorrosive media. It features a 2-1/2 IN dial, a measuring range of 0 - 160 PSI, and a 1/4 IN NPT lower connection.

• Cost-effective
• General purpose instrument
• Reliable pressure measurements

Product Highlights

This gauge is designed for pressure measurements with water, oil, air, gas or other noncorrosive media.

Product Information

Standard Information

• Brand: MARSH BELLOFRAM
• Manufacturer Part Number: J4652
• Country of Origin: United States

Technical Specifications

• Dial Size: 2-1/2 IN
• Measuring Range: 0 - 160 PSI
• Units Of Measure: PSI, KPA
• Connection: 1/4 IN NPT Lower
• Accuracy: Plus/Minus 3-2-3% (ASME Grade B)
• Dial Face: Black Markings On White
• Case Material: Black Steel
• Lens: Acrylic Twist-In Clearlok
• Pointer Material: Black Aluminum
• Movement Material: Brass
• Tube Material: Copper Alloy
• Socket Material: Copper Alloy
• Length: 2.73 IN
• Width: 2.73 IN
• Depth: 1.22 IN
• Filled With: Dry
• Case Style: Lower Mount
• Range: 0 to 160 psi
• Dial Standard: Dual scale psi and kPa
• Pointer: Aluminum, black painted
• Window: Acrylic, twist-in Clearlok
• Manufacturer: MARSH
• Series: General Service Series
• Model: J4652
• Stock #: 10141
• Case Type: Plain
• Case: Black Steel
• Primary Range: 0-160 psi
• Secondary Scale: kPa
• Gauge Type: Pressure
• Connection Location: Bottom
• Connection Size: 1/4" NPT
• Lens Type: Acrylic
• Dry or Filled: Dry
• Wetted Parts: Copper
• Additional Info: MARSH General Service Series Utility Gauges with a Steel - Black Plain Case, 1/4" NPT Bottom Mount, Acrylic Lens, Dry, Copper Wetted Parts, ASME Grade B, Made in China
• Brand: MARSH
