Marsh Bellofram J4646 2-1/2 0-60 PSI Gauge Dry 1/4 Lm

Product Description

The Marsh Bellofram J4646 general service steel case gauge is designed for reliable pressure measurements. It is suitable for use with water, oil, air, gas or other noncorrosive media from vacuum/compound through 5000 PSI. This gauge offers high-repeatability pressure measurement capabilities across a variety of applications.

• Cost-effective
• General purpose
• Reliable pressure measurements
• Suitable for use with water, oil, air, gas or other noncorrosive media

Product Highlights

This gauge is designed for reliable pressure measurements and suitable for use with various noncorrosive media. It features a black steel case and an acrylic twist-in Clearlok lens.

Product Information

Standard Information

• Brand: MARSH BELLOFRAM
• Manufacturer Part Number: J4646
• Country of Origin: China

Technical Specifications

• Dial Size: 2-1/2 IN
• Measuring Range: 0 - 60 PSI
• Units Of Measure: PSI, KPA
• Connection: 1/4 IN NPT Lower
• Accuracy: Plus/Minus 3-2-3% (ASME Grade B)
• Graduations: 1 Smallest, 10 Largest
• Dial Face: Black Markings On White
• Case: Black Steel
• Lens: Acrylic Twist-In Clearlok
• Pointer Material: Black Aluminum
• Movement: Brass
• Tube Material: Copper Alloy
• Socket Material: Copper Alloy
• Length: 2.73 IN
• Width: 2.73 IN
• Depth: 1.22 IN
• Item Name: General Service Pressure Gauge
• Filled With: Dry
• Part #: J4646
• Model: J4646
• MPN: J4646
• Brand: Marsh/ Bellofram
• Manufacturer: MARSH
• Series: General Service Series
• Case Type: Plain
• Case Material: Steel - Black
• Primary Range: 0-60 psi
• Secondary Scale: kPa
• Gauge Type: Pressure
• Connection Location: Bottom
• Connection Size: 1/4" NPT
• Lens Type: Acrylic
• Dry or Filled: Dry
• Wetted Parts: Copper
• Face Diameter: 2.5 in (63 mm)
• Connection Diameter: 1/4 in
• Mounting Position: Side/Bottom Mount
• Maximum Pressure: 60 psi/ 400 kpa
