Marsh Bellofram J4614 Gauge 2-1/2 1/4 Lm Compound 30-Vacuum-0-60 PSI

Product Description

The MARSH BELLOFRAM J4614 general service steel case gauge is designed for reliable pressure measurements. Suitable for use with water, oil, air, gas, or other noncorrosive media from vacuum/compound through 5000 PSI. Features a 2-1/2 IN dial and measures from 30 IN Hg - 60 PSI. It has black markings on a white dial face.

• Cost-effective
• General purpose
• Reliable pressure measurements

Product Highlights

This gauge is suitable for use with water, oil, air, gas or other noncorrosive media.

Product Information

Standard Information

• Brand: MARSH BELLOFRAM
• Manufacturer Part Number: J4614
• Country of Origin: China

Technical Specifications

• Dial Size: 2-1/2 IN
• Connection Size: 1/4 IN NPT
• Measuring Range: 30 IN Hg - 60 PSI
• Units Of Measure: PSI, KPA
• Connection: 1/4 IN NPT Lower
• Accuracy: Plus/Minus 3-2-3% (ASME Grade B)
• Graduations: 2/2 Smallest, 10/10 Largest
• Dial Face: Black Markings On White
• Case: Black Steel
• Lens: Acrylic Twist-In Clearlok
• Pointer Material: Black Aluminum
• Movement: Brass
• Tube Material: Copper Alloy
• Socket Material: Copper Alloy
• Depth: 1.22 IN
• Item Name: General Service Compound Pressure Gauge
• Filled With: Dry
• Gauge Case Material: Steel
