Marsh Bellofram G22705 2-1/2 0-60 WC Diaphragm Gauge 1/4 LBM

Product Description

The MARSH BELLOFRAM G22705 low pressure gauge incorporates a diaphragm element, allowing for accurate low-pressure readings. It features a 2-1/2 IN dial and a measuring range of 0 - 60 IN H2O. The gauge has ASME grade A 2/1/2% accuracy for ranges above 30 IN of water and a 1/4 IN NPT lower back connection.

• Diaphragm internals for accurate low pressure measurement
• 2-1/2 IN dial size
• Accuracy of Plus/Minus 2-1-2% (ASME Grade A)

Product Highlights

This diaphragm gauge provides accurate low-pressure readings with a clear dial face and robust construction.

Product Information

Standard Information

• Brand: MARSH BELLOFRAM
• Manufacturer Part Number: G22705
• Country of Origin: United States

Technical Specifications

• Dial Size: 2-1/2 IN
• Measuring Range: 0 - 60 IN H2O
• Units Of Measure: IN H2O, KPA
• Connection: 1/4 IN NPT Lower Back
• Accuracy: Plus/Minus 2-1/2% (ASME Grade A)
• Dial Face: Black Markings On White
• Case: Black Steel
• Lens: Acrylic Twist-In Clearlok
• Pointer Material: Black Aluminum
• Movement: Brass
• Socket: Brass
• Item Name: Low Pressure Diaphragm Gauge
• Case Material: Black Steel
• Lens Material: Acrylic Twist-In Clearlok
• Movement Material: Brass
• Socket Material: Brass
• Brand: MARSH INSTRUMENTS
• MPN: G22705
