Marsh Bellofram G22695 2-1/2 0-160 WC Diaphragm Gauge 1/4 LBM

Product Description

The MARSH BELLOFRAM G22695 is a low pressure diaphragm gauge designed for accurate low-pressure readings in various applications. It features a 2-1/2 IN dial and measures pressure ranging from 0 to 160 IN H2O, with units of measure in IN H2O and KPA. The gauge offers ASME grade A 2/1/2% accuracy for ranges above 30 IN of water.

• 2-1/2 IN dial
• Measuring range: 0 - 160 IN H2O
• Connection: 1/4 IN NPT Lower Back

Product Highlights

This diaphragm gauge provides accurate low-pressure readings with a black steel case and acrylic twist-in Clearlok lens.

Product Information

Standard Information

• Brand: MARSH BELLOFRAM
• Manufacturer Part Number: G22695
• Country of Origin: United States

Technical Specifications

• Dial Size: 2-1/2 IN
• Measuring Range: 0 - 160 IN H2O
• Units Of Measure: IN H2O, KPA
• Connection: 1/4 IN NPT Lower Back
• Accuracy: Plus/Minus 2.5% (ASME Grade A)
• Dial Face: Black Markings On White
• Case: Black Steel
• Lens: Acrylic Twist-In Clearlok
• Pointer Material: Black Aluminum
• Movement: Brass
• Socket: Brass
