Marsh Bellofram G22687 2-1/2 0-100 WC Diaphragm Gauge 1/4 LBM

Product Description

The MARSH BELLOFRAM G22687 low pressure gauge incorporates a diaphragm element, allowing for accurate low-pressure readings in various applications. It features a 2-1/2 IN dial and a measuring range of 0 - 100 IN H2O with ASME grade A 2/1/2% accuracy for ranges above 30 IN of water. The gauge supports units of measure in IN H2O and KPA.

• Low pressure diaphragm gauge
• ASME grade A 2/1/2% accuracy for ranges above 30 IN of water
• Diaphragm internals for accurate low pressure measurement

Product Highlights

Dependable performance and accuracy for low pressure readings in a variety of applications.

Product Information

Standard Information

• Brand: MARSH BELLOFRAM
• Manufacturer Part Number: G22687

Technical Specifications

• Dial Size: 2-1/2 IN
• Measuring Range: 0 - 100 IN H2O
• Units Of Measure: IN H2O, KPA
• Connection: 1/4 IN NPT Lower Back
• Accuracy: Plus/Minus 2-1-2% (ASME Grade A)
• Dial Face: Black Markings On White
• Case: Black Steel
• Lens: Acrylic Twist-In Clearlok
• Pointer Material: Black Aluminum
• Movement: Brass
• Socket: Brass
• Item Name: Low Pressure Diaphragm Gauge
• Case Material: Black Steel
• Lens Material: Acrylic Twist-In Clearlok
• Movement Material: Brass
• Socket Material: Brass
• MPN: G22687
• Brand: MARSH INSTRUMENTS
• Range: 0 to 100" H2O
• Wetted material: bronze
• Case material: painted steel
• Process connection: 1/4" NPT(M), lower mount
• Smallest graduations: 2.0" H2O
• Pointer: aluminum
