Product Description
The MARS STD242-1UA-OB air curtain is designed for multipurpose use. This unheated air curtain is suitable for doorways of 10 to 12 ft, maintaining temperatures and preventing contamination. It features a 1/2 horsepower motor, providing ample power while reducing energy consumption. The metal case is coated with rust-resistant electrostatic polyurethane for increased durability.
- Maintains temperatures and prevents contamination
- Equipped with a 1/2-horsepower continuous duty motor
- Features an automatic on/off function
Product Highlights
This 42-inch air curtain creates an environmental barrier, protecting spaces from insects and maintaining consistent temperatures.
Product Information
Standard Information
-
Brand: MARS
-
Manufacturer Part Number: STD242-1UA-OB
-
Country of Origin: United States
Technical Specifications
-
Item: Air Curtain
-
Depth: 12 5/8 in
-
Phase: 1
-
Width: 16.400
-
Finish: Galvanized, Powder Coated
-
Height: 10 5/8 in
-
Series: STD2 (Standard 2)
-
Voltage: 110-120V
-
Max. RPM: 1,750 RPM
-
Motor HP: 1/2 hp
-
Frequency: 60 Hz
-
Max. Amps: 5.1
-
Standards: ETL
-
Drive Type: Direct Drive
-
Motor Type: Permanent Split Capacitor
-
Nozzle Width: 42 in
-
Profile Type: Standard Profile
-
Housing Color: Black
-
Maximum Speed: 1,750 RPM
-
Grille Material: Steel
-
Motor Enclosure: Totally Enclosed Air Over
-
Nominal Voltage: 120V AC
-
Air Curtain Item: Air Curtain
-
Air Curtain Type: Ambient Air
-
Number of Motors: 1.0
-
Number of Speeds: 3
-
Full Load Current: 5.1 A
-
Heated/Not Heated: Not Heated
-
Nameplate Voltage: 115V AC
-
Power Consumption: 510 W
-
Air Curtain Finish: Galvanized
-
Air Curtain Heated: No
-
Maximum Air Volume: 1,418 cfm
-
Sound Level @ 10 ft: 66 dBA
-
Air Temperature Rise: Not Applicable
-
Max. Mounting Height: 10 ft
-
Maximum Air Velocity: 4,865 fpm
-
Electrical Connection: Not Available
-
Air Curtain Air Volume: 1418 cfm
-
For Frame Opening Width: 3 1/2 ft
-
Nameplate Voltage/Phase: 115V AC - 1 Ph
-
Nominal Voltage - Phase: 120V AC - 1 Phase
-
Air Curtain Air Velocity: 2925 fpm
-
Heater Power Consumption: Not Applicable
-
Air Curtain dBA @ 10 Feet: 66
-
Motor Horsepower per Motor: 1/2 hp
-
Air Curtain Max. Door Width: 3.5 ft
-
Air Curtain Housing Material: Steel
-
Mounting Height for Insect Control: 10 ft
-
Country of Origin (subject to change): United States
-
Max. Mounting Height Environment/Insect: 12 ft / 10 ft
-
Mounting Height for Temperature Control: 12 ft
-
MPN: STD242-1UA-OB
-
Environmental - Max Height (feet): 12
-
Insect - Max Height (feet): 10
-
Heating Mode: Unheated
-
Nozzle Width (inches): 42
-
Unit Width (inches): 42
-
Unit Height (inches): 10.625
-
Wind Stopping Capability (MPH): 12
-
Motors: 1
-
Air Flow Certified (AMCA): Yes
-
Voltage Rating: 115/1/60
-
Voltage Code: A
-
Amps: 5.1
-
Uniformity (%): 87
-
dBA: 66
-
Manufacturer: Mars
-
Product Condition: New
-
Product Type: Facility Maintenance
-
Temperature: Unheated
-
Type: Unheated
-
Hertz: 60
-
Length (in): 42
-
CFMs: 1418
-
Depth (in.): 12.75
-
Height (in.): 10.625
-
Certifications: ETL Listed, AMCA
-
Brand: MARS
-
Compatible Brand: MARS
-
Model: STD242-1UA-OB
-
Features: Unhtd 10.7 In.H 42 In.W 13 In.D Steel Air Curtain, For Frame Opening Width 3 1/2 ft, Mounting Height for Temperature Control 12 ft, Overall Depth 13 in, Overall Height 10 5/8 in, Overall Width 42 in, Profile Type Standard Profile, Heated/Not Heated Not Heated, Maximum Air Velocity 4, 865 fpm, Mounting Height for Insect Control 10 ft, Maximum Air Volume 1, 418 cfm, Nameplate Voltage 115V AC, Air Temperature Rise Not Applicable, Sound Level @ 10 ft 66 dBA, Housing Color Black, Phase 1
