MARS Motors and Armatures 50354 Mars Power Transformer 40VA 120/208/240VAC Primary 24VAC Secondary

Product Description

MARS Motors and Armatures 50354 is a power transformer designed for efficiency. This transformer operates with a KVA rating of forty volts-amperes and includes a primary voltage range of 120 to 240 volts. The secondary voltage is twenty-four volts. Ideal for control circuits in HVAC, heating, or refrigeration systems.

• KVA Rating: 40VA
• NEMA Class II enclosure
• UL5085 listed for safety

Product Highlights

This compact transformer features color-coded leads for easy connections and a foot-mount design making installation straightforward.

Product Information

Standard Information

• Manufacturer: MARS Motors and Armatures
• UPC: Not provided

Technical Specifications

• Type: Power
• KVA Rating: 40VA
• Primary Voltage: 120/208 to 240VAC
• Secondary Voltage: 24VAC
• Frequency: 50/60 Hz
• Connection: Primary color-coded leads; secondary: color-coded leads or 1/4 inch male quick connects
• Mounting: Foot
• Enclosure: NEMA Class II
• Width: 2.146 inches
• Height: 2.244 inches
• Standards: UL5085 Listed
• Applications: For use to provide power source for control circuits in air conditioning and refrigeration systems
