Mars MARS-80316 Fused Disconnect 30 Amp 240 Vac

Product Description

The MARS MARS-80316 is a 30-amp fused disconnect designed for single-phase HVAC and refrigeration equipment operating at up to 240 VAC. It provides a local means of disconnecting power to condensing units, air handlers, and other outdoor or indoor equipment that requires a service disconnect at the unit. The switch is fusible, accepts standard cartridge fuses, and is rated for 50/60 Hz service. UL Listed construction confirms it meets recognized safety standards for electrical disconnect applications. Licensed electricians and HVAC technicians install this type of disconnect as required by NEC Article 440 for motor-driven refrigeration and air conditioning equipment.

The MARS-80316 is suited for residential and light commercial split-system air conditioners, heat pumps, and packaged units where a fused, two-pole disconnect is required at or near the equipment. It handles single-phase loads up to 30 amps at 240 VAC, making it appropriate for most residential condensing units in the 1.5- to 5-ton range. The compact footprint allows installation in standard disconnect enclosures or direct surface mounting near the equipment served.

Key Features

• 30-amp rating at 240 VAC for single-phase HVAC and refrigeration loads
• Fusible two-pole switch provides overcurrent protection at the disconnect point
• Rated for both 50 Hz and 60 Hz systems
• UL Listed for compliance with recognized electrical safety standards
• California Proposition 65 compliant labeling included

Compatibility

Designed as an OEM-style replacement or new-installation fused disconnect for single-phase residential and light commercial HVAC and refrigeration equipment rated up to 30 amps and 240 VAC.

Installation Notes

Installation should be performed by a licensed electrician or qualified HVAC technician in accordance with NEC Article 440 and all applicable local codes. Disconnect and lock out the supply circuit before handling any wiring connections. Verify that the fuse amperage used does not exceed the equipment nameplate maximum overcurrent protection rating. Mount the disconnect within sight of the equipment it serves as required by code.

Technical Specifications

• Amperage: 30 amps
• Maximum Voltage: 240 VAC
• Phase: Single
• Poles: 2
• Switch Type: Fused
• Frequency: 50/60 Hz
• Height: 1.65 inches
• Length: 1.98 inches
• Width: 2.13 inches
• Weight: 3.91 pounds
• Approvals: UL Listed
• Proposition 65: Yes
• Country of Origin: China

Standard Information

• Brand: MARS
• Manufacturer Part Number: MARS-80316
