Mars M10584 Direct Drive Furnace Blower Motor 1/4 hp

Product Description

The MARS M10584 direct drive furnace blower motor is a three-speed standard efficiency model. It is electrically reversible and includes 2-1/4 in resilient rings for base mounting. This motor features all angle sleeve bearings and an open air over enclosure. Requires a 5 uF at 370 VAC capacitor, not included.

• Features Rheem mounting holes
• Includes 1/2 in extended thru-bolt
• Offers fan duty, continuous, air-over operation

Product Highlights

This 1/4 hp motor operates at 208 to 230 VAC, 60 Hz, and 1 phase, with a speed of 1075 rpm. It has a 48 frame and all angle mounting.

Product Information

Standard Information

• Brand: MARS
• Manufacturer Part Number: M10584

Technical Specifications

• Amperage Rating: 1.8 A Full Load
• Bearing Type: Sleeve
• Enclosure Type: OAO
• Frame: 48
• Frequency Rating: 60 Hz
• Horsepower: 1/4 hp
• Insulation Class: Class B
• Mounting Type: All Angle
• Number of Speeds: 3
• Phase: 1
• Rotation: Reversible
• Shaft Size: 1/2 in Dia x 4-1/2 in L
• Speed: 1075 rpm
• Temperature Rating: 60 deg C
• Voltage Rating: 208 to 230 V AC
• Motor Thermal Protection: Auto
• RPM Range: 1001-1100
• Type: Permanent Split Capacitor
• Variety: PSC
• Ambient Temperature Rating: 40 Deg C
• Full Load Amps: 1.8
• Motor Phase: 1
• Motor RPM: 1075
• Run Capacitor: 5/370
• Shaft Length: 4.5 in
• Power Rating: 1/4 HP
• Motor FLA: 1.8 Amp
• Speed Rating: 1075 RPM
• NEMA Frame Size: 48
• Application: HVAC, Blower
• Approval: UL, CUL
• Diameter: 5-1/2 Inch
• Lead Length: 36 Inch
• Frequency: 60Hz
• Reversible: Yes
