Mars M10583 Furnace Blower Motor 1/4hp 115V OAO PSC

Product Description

The MARS M10583 is a 1/4 HP, 115 VAC, 60 Hz, 1-Phase, direct drive blower motor. It features a 4.2 A, 1075 RPM, 3-speed, reversible design with Class B insulation and sleeve bearings. Suitable for all angle mounting with an open air over enclosure (OAO).

• Three speed standard efficiency model
• Electrically reversible and includes 2-1/4 inch resilient rings for base mounting
• Features all angle sleeve bearings and an open air over enclosure

Product Highlights

Direct drive furnace blower motor with electrical reversibility and all-angle mounting.

Product Information

Standard Information

• Brand: MARS
• Manufacturer Part Number: M10583

Technical Specifications

• Enclosure Type: OAO
• Power Rating: 1/4 HP
• Voltage Rating: 115 Volt AC 1-Phase
• Frequency Rating: 60 Hertz
• Motor FLA: 4.2 Amp
• Number of Speeds: 3
• Speed Rating: 1075 RPM
• Reversible: Yes
• NEMA Frame Size: 48
• Insulation Class: B
• Mounting: All Angle
• Application: HVAC, Blower
• Approval: UL, CUL
• Type: Permanent Split Capacitor
• Bearing Type: Sleeve
• Diameter: 5.5 Inch
• Shaft Size: 1/2 Inch Diameter x 4.5 Inch Length
• Lead Length: 36 Inch
• Ambient Temperature Rating: 40 Deg C
• Brand: MARS
• Motor Thermal Protection: Auto
• Rotation: Clockwise, Counter Clock Wise
• RPM Range: 1001-1100
• Variety: PSC
• Voltage: 115V
• Frequency: 60Hz
• Full Load Amps: 4.2
• Motor Phase: 1
• Motor RPM: 1075
• Run Capacitor: 5/370
