Mars HV248-1UA-TS Series 2 Unheated High Velocity Air Curtain W/ 48 inches Wide Door, 4000 CFM, 115V, 1PH

Product Description

The MARS HV248-1UA-TS Series 2 unheated high-velocity air curtain reduces energy costs and consumption. It creates effective environmental separation and maintains interior building temperature. The durable metal construction has a corrosion-resistant powder-coated finish and is easy to install with low maintenance. It is designed for door heights of 12-14'.

• Reduces energy costs and consumption
• Creates effective environmental separation
• Maintains interior building temperature
• Minimizes dirt, dust, and fumes

Product Highlights

This unheated air curtain is ideal for industrial applications, effectively separating environments and protecting openings with significant wind loads.

Product Information

Standard Information

• Brand: MARS
• Manufacturer Part Number: HV248-1UA-TS
• Country of Origin: USA

Technical Specifications

• CFM: 4000 CFM
• Type: Standard
• Brand: Mars
• Phase: 1
• Series: HV2 (High Velocity 2) Series
• Voltage: 115 V
• Decibels: 70
• Material: Galvanized Steel
• Horsepower: 1 HP
• Heating Option: Unheated
• Door Width: 48 in
• Door Height: 10' - 12'
• Max Door Height: 12 ft
• Manufacturers Part Number: HV248-1UA-TS
• Environmental - Max Height (feet): 14
• Insect - Max Height (feet): 12
• Heating Mode: Unheated
• Nozzle Width (inches): 48
• Unit Width (inches): 48
• Unit Height (inches): 14
• Wind Stopping Capability (MPH): 12
• Motors: 1
• Voltage Rating: 115/1/60
• Voltage Code: A
• Air Curtain Air Volume (CFM): 2447
• Amps: 9
• Uniformity (%): 88
• Application: Shipping & Receiving Areas
• ETL Listed: Yes
• HP: 1 HP
• Max Environmental Separation Height: 14 Feet
• Max Insect Blocking Height: 12 Feet
• Power: Electric
• Volts: 115 Volts
• Wattage: 1,360 Watts
• Hertz: 60
• Length (in): 48
• Product: Air Curtains
• Product Type: Facility Maintenance
• Temperature: Unheated
• Number of Poles: 1
• Max Volume: 4000
• Max Velocity: 4000
• Frequency (Hertz): 60
• AMCA Uniformity: 88
• Sound dBA: 70
• FLA (Ampacity): 9Amps
