MARS 90341 Series 903 110/120V Double Pole Double Throw Relay

Product Description

The MARS Series 903 110/120V Double Pole Double Throw Relay, with MPN 90341, is designed for various electrical control applications. This relay features a durable construction suitable for HVAC systems. It uses quick-connect terminals for efficient installation and maintenance.

• Voltage Rating: 96 VAC pick-up, 24 VAC drop-out
• Amperage Rating: 25 A at 277 VAC resistive, 15 A at 277 VAC inductive
• CSA Certified and UL Listed for safety standards

Product Highlights

This relay is ideal for air conditioning, heating, and refrigeration systems.

Product Information

Standard Information

• Brand: MARS
• MPN: 90341

Technical Specifications

• Coil Voltage: 110/120 VAC
• Dimensions: 2.13 inches L x 1.88 inches W x 2.25 inches D
• Contact Material: Silver Cadmium Oxide
• Mounting Type: Flange
• Terminal Type: Quick Connect
• Voltage Rating: 96 VAC Pick-Up, 24 VAC Drop Out, 60 Hz
• Amperage Rating: 25 A at 277 VAC Resistive, 15 A at 277 VAC Inductive
• Standard/Approvals: CSA Certified, UL Listed
