Mars 62442 208-240V 40A 2P DP Contactor (2-Pole)

Product Description

The MARS 62442 is a two-pole definite-purpose contactor rated for 208–240 V and 40 A, intended for control of refrigeration, air conditioning, and electric heating equipment. The unit features box lug and dual quick-connect terminals, a removable coil and cover for field service, and a thermoplastic housing with oversized wiring access. It is engineered with copper and brass conductors and meets UL standards.

• Rated 208–240 V operating voltage with 40 A inductive full-load amp rating (50 A resistive rating).
• Box lug and dual quick-connect terminals with oversized "Arch Window" wiring access; two QC terminals per pole.
• Removable coil and removable cover; thermoplastic housing and copper/brass conductors; UL listed.

Product Highlights

Definite-purpose 2-pole contactor, 208–240 V, 40 A inductive (50 A resistive), box lug/dual QC terminals, removable coil and cover.

Product Information

Standard Information

• Brand: MARS
• Manufacturer Part Number: 62442

Technical Specifications

• Brand: MARS
• MPN: 62442
• Model: 62442
• Type: Definite purpose contactor (double pole)
• Number of Poles: 2 (in 3-pole body)
• Operating Voltage: 208-240 V
• FLA Inductive Amps: 40 A
• FLA Resistive Amps: 50 A
• Coil Voltage: 120 V
• Coil Frequency: 50/60 Hz
• Terminal Type: Box lug / Dual quick-connect
• Number of QC Terminals Per Pole: 2
• Housing Material: Thermoplastic
• Conductors: Copper and brass
• Removable Coil: Yes
• Removable Cover: Yes
• Wiring Access: Oversized "Arch Window"
• Standards: UL
• Dimensions (W x H x D): 2.38 in x 2.87 in x 3.69 in
