MARS 22464 MOTOR BLO DR DIR FAN & BLO MOTORS 1/2HP

Product Description

The MARS 22464 is a 1/2 horsepower direct drive motor designed for blower applications. This motor features Rheem mounting holes for easy installation. It is equipped with a sleeve bearing, torsion mount sleeves, and grommets for flexibility in installation. The motor provides four speeds, operates on a single phase, and comes thermally protected to ensure safety during use. The lead length is thirty-two inches.

• No. of Poles: 6
• Voltage: 208-230
• Rotation: Reverse

Product Highlights

This motor is suitable for various HVAC applications, providing reliable performance with a continuous duty rating.

Product Information

Standard Information

• Motor Type: PSC
• Enclosure: OAO

Technical Specifications

• HP (Max.): 1/2
• Mounting: Belly Band, Resilient Ring
• Speeds: 4
• Hz: 60
• NEMA Frame Size: 48
• Phase: Single
• FLA: 2.7
• Lead Length (in.): 32
• Ambient Temperature (Deg C): 40
• Insulation Class: B
• Shaft Diameter (in.): 1/2
• Shaft Length (in.): 5.5
• Capacitor Rating: 10/7.5/5/370
• Service Factor: 1.0
• Duty: Continuous
