MARS 10584 Mars Direct Drive 3-Speed Blower Motor 1/4 HP 208 - 230V

Product Description

The Mars Direct Drive 3-Speed Blower Motor, MPN 10584, is suitable for HVAC applications. This motor operates at one-fourth horsepower and provides a speed of one thousand seventy-five revolutions per minute. It functions at a voltage range of two hundred eight to two hundred thirty volts and is designed for 1-phase systems. The mounting method consists of resilient rings and through bolts.

• Reversible rotation for versatile setup
• Suitable for residential and commercial HVAC systems
• Compact design with NEMA 48 frame

Product Highlights

This motor is essential for effective airflow in heating and cooling systems, providing reliable operation across various environments.

Product Information

Standard Information

• Brand: MARS Motors and Armatures
• Part Number: 10584

Technical Specifications

• Item Name: Blower Motor
• Type: Blower Motor
• Voltage Rating: 208 to 230V
• Horse Power: 1/4 HP
• Phase: 1-Phase
• Shaft Diameter: 1/2 inch
• No Load RPM: 1075 rpm
• Mounting: Resilient Rings, Thru Bolts
• Shaft Length: 4-1/2 inch
• Frame: NEMA 48
• Amperage Rating: 1.8A FLA
• Bearing Type: Sleeve
• Rotation: Reversible
