MARS 10466 Mars Multi-Horse Power Direct Drive 4 Speed 1-Phase Reversible Blower Motor, 1075 rpm, 1/5 - 3/4 HP

Product Description

The MARS Motors and Armatures 10466 is a versatile blower motor designed for HVAC applications. This direct drive motor operates at a speed of 1075 rpm and provides a power range of 1/5 to 3/4 horsepower. It operates on a voltage rating of 115 volts and is suitable for one-phase systems.

• Speed: 1075 rpm
• Power Range: 1/5 to 3/4 HP
• Voltage: 115V

Product Highlights

This motor features a reversible rotation, making it adaptable for different setups. The resilient ring mounting offers stability during operation, and its NEMA 48 frame size simplifies installation in most systems.

Product Information

Standard Information

• Brand: MARS Motors and Armatures
• Part Number: 10466

Technical Specifications

• Horse Power: 1/5 HP
• Phase: 1-Phase
• Voltage Rating: 115V
• No Load RPM: 1075 rpm
• Shaft Diameter: 1/2 inch
• Shaft Length: 5.8 inch
• Frame: NEMA 48
• Amperage Rating: 8.5A
• Bearing Type: Ball
• Mounting: Resilient Rings
