Marks Hardware M9900F-32D Fire-Rated Rim Exit Device

Product Description

The Marks Hardware M9900F-32D exit device is a reliable solution designed for panic and fire-rated applications. It is built with a heavy-duty cast chassis for durability and suitable for retrofit in most pre-existing door setups. The smooth touchbar assembly enhances safety by reducing potential catch hazards. It features a mitered steel flush-mounted Panic Protector End Cap.

• Heavy-duty construction
• Grade 1 rating for high-impact use
• Compatible with various door preps

Product Highlights

This exit device meets ANSI/BHMA standards and is UL Listed for a three-hour fire rating. It is equipped with a stainless steel latchbolt offering secure locking capabilities.

Product Information

Standard Information

• Brand: Marks USA
• Usage: Heavy Duty

Technical Specifications

• Fire Rating: UL Listed, 3-hour fire-rated for doors up to thirty-eight inches x eighty-six inches
• Latchbolt: Stainless Steel 3/4 inch throw with 5/8 inch Stainless Steel Dead Latch
• Door Thickness: 1-3/4 inches
• Warranty: Limited Lifetime Warranty
• Strike: Roller Strike
• Mount: Rim
• Door Width: Thirty-three inches to thirty-six inches
• Grade: 1
