MARKS HARDWARE 175RAB26D-3/4 SFIC Entry Lever Lockset, Small Format IC, Less Core, 2-3/4 inches Backset, ANSI Strike, Grade 2

Product Description

The MARKS HARDWARE 175RAB26D-3/4 SFIC Entry Lever Lockset is a reliable choice for secure entry. This lockset is built with a small format IC design and features a two and three-fourths inch backset. The locking mechanism is straightforward, with a turn-button inside and key access from outside. Users can easily unlock by rotating the inside lever, which releases the outside lever control.

• Features a field reversible handing for easy installation.
• Compatible with SFIC core cylinder for enhanced security.
• Angled return lever style for practical use.

Product Highlights

Ideal for commercial applications, this lockset combines functionality and security standards.

Product Information

Standard Information

• Brand: MARKS HARDWARE
• Type: SFIC Entry Lever Lockset

Technical Specifications

• Grade: Grade 2
• Backset: 2-3/4 inches
• Handing: Field reversible
• Function: Entry
• Cylinder Included: No
• Cylinder Type: SFIC Core Cylinder
• Lever Style: Angled Return Lever
• Strike Size: 4-7/8 inches x 1-1/4 inches
• Latch Bolt Type: Deadlatch
• Knob/Lever Design: 175
• Rose/Escutcheon Size: 2-9/16 inches
• Latch Bolt Faceplate Size: 2-1/4 inches x 1-1/8 inches
• Door Bore Size: 2-1/8 inches
• Lock Category: Cylindrical Lock
• Door Thickness Min: 1-5/8 inches
• Latch Bolt Face Type: Square Corner
• Latch Bolt Throw: 1/2 inch
• Rose/Escutcheon Style: Rose
• Door Thickness Max: 1-7/8 inches
• Knob/Lever Style: Lever
• Height: 4 inches
• Length: 8.38 inches
• Width: 7.13 inches
• Manufacturer: Marks USA
• Category: Commercial Locks, Cylindrical Levers, Lock Sets
• Certifications: A156.2, ANSI, UL Listed 3 Hour
• Door Application: Lock Sets
• Faceplate Height: 2-1/4 inches
• Faceplate Width: 1-1/8 inches
• Finish Code: 626
• Fire Rated: Yes
• Fire Rating: 120 min
