Marathon Special Products R60A2B Reinforced Class R Fuseblock 60A 2-Pole Panel Mount 96F5442

Product Description

Marathon Special Products R60A2B is a reinforced two-pole Class R fuseblock rated 60 A at 250 V for panel-mount installations. It is constructed of thermoplastic and uses box lug terminals with reinforced spring clips. The block is UL listed and CSA certified and is designed to accommodate Class R power fuses (250 V and 600 V) and various terminal options for equipment and panel fuse protection.

• Two-pole Class R fuseblock rated 60 A at 250 V; accommodates Class R 250 V and 600 V fuses
• Panel-mount thermoplastic construction with box lug terminals and reinforced spring clips
• Certifications: UL, CSA, CE; compact dimensions 2.01 in x 2.86 in x 4.83 in; net weight 0.23 lb

Product Highlights

Reinforced 2-pole Class R fuseblock, 60 A/250 V rating, panel mount with box lug terminals and UL/CSA/CE approvals.

Product Information

Standard Information

• Brand: MARATHON SPECIAL PRODUCTS
• Manufacturer Part Number: R60A2B
