Marathon Special Products 601GP10PSB Barrier strip 20A (20 position) 0630066

Product Description

Marathon Special Products 601GP10PSB is a panel-mount barrier strip that provides 20 screw-terminated positions for electrical connections. It features an 11.1 mm pitch, accepts 12–22 AWG copper wire, and is rated for 20 A and 300 VDC/VAC. The double-row open-back insulator strip supports operation up to 150 °C and is RoHS compliant. Typical uses include power distribution, terminal wiring, and panel accessories.

• 20 screw-terminated positions with 11.1 mm pitch for panel-mount installations
• Electrical ratings: 20 A maximum current, 300 VDC/VAC maximum voltage; accepts 12–22 AWG
• Double-row open-back insulator strip for copper wire only; operating temperature up to 150 °C; RoHS compliant

Product Highlights

20-position panel-mount barrier strip with 11.1 mm pitch, 20 A/300 V rating, accepts 12–22 AWG, RoHS compliant

Product Information

Standard Information

• Brand: MARATHON SPECIAL PRODUCTS
• Manufacturer Part Number: 601GP10PSB
• Country of Origin: Mexico
