Marathon Special Products 207 Terminal Block Connector 30A (7 Position) 671GP07

Product Description

The Marathon Special Products 207 is a heavy-duty double-row terminal block connector designed for multi-position, high-current electrical connections. It is a 7-position, screw-clamp terminal with top wire entry and phenolic-style closed-back construction. The connector is rated for 30 A and listed at 150 V / 300 V, accepts 22-10 AWG conductors, and is RoHS compliant with CE, CSA, and UR approvals for control and wiring applications.

• Heavy-duty double-row, closed-back terminal block with screw-clamp connections and top wire entry
• Electrical ratings: 30 A current, rated 150 V / 300 V; accepts 22-10 AWG wire
• Surface-mount design with 11.1 mm center spacing and 0.42" mounting hole

Product Highlights

7-position surface-mount terminal block, 30 A rating, screw-clamp connections, RoHS compliant

Product Information

Standard Information

• Brand: MARATHON SPECIAL PRODUCTS
• Manufacturer Part Number: 207
