Marathon Motors S110 Electric Motor 1/3 HP 1725 RPM

Product Description

The Marathon Motors S110 is a general-purpose electric motor with a robust design ideal for various applications. This motor operates effectively in environments that are clean and dry, making it suitable for tools, belt drive fans, blowers, and coolers. The drip-proof enclosure protects the motor while ensuring quiet operation and reduced vibration.

• General-purpose motor
• 1/3 HP power rating
• Speed of 1725 RPM

Product Highlights

UL recognized and CSA certified, this motor features a heavy gauge steel frame for durability.

Product Information

Standard Information

• Brand: Marathon Motors
• MPN: S110

Technical Specifications

• Catalog Number: S110
• HP: 1/3
• Voltage: 115/230
• Frequency: 60 Hz
• Amps: 7.0/3.5
• RPM (Nameplate): 1725
• Speeds: 1
• Phase: 1
• Enclosure Type: Drip Proof
• Rotation: Selective Counterclockwise
• Mounting Type: Resilient Base
• Frame Type: 48
• Frame Material: Rolled Steel
• Shaft Diameter: 1/2 inches
• Shaft Extension: 1.56 inches
• Shaft Type: NEMA 48
• DE Bearing Type: Ball
• ODE Bearing Type: Ball
• C-Dimension: 9.31 inches
• Electrical Type: Capacitor Start Induction Run
• Duty: Continuous
• Motor Orientation: Horizontal
• Service Factor: 1
• Insulation Class: B
• Max Ambient: 40°C
• IP Code: 22
• FL Amps: 7/3.5
• FL Efficiency: 59.5%
• Starting Type: Capacitor Start Induction Run
• Weight: 16 lbs
