MARATHON MOTORS MR836 Three-Phase Electric Motor 20 hp
Availability:
In Stock
Ships via freight in 1-3 business days
%3Cp%3EEarn%20[points_amount]%20when%20you%20buy%20this%20item.%3C/p%3E
- $2,966.94
- $2,966.94
- Unit price
- / per
✓
Better Price in Cart
Manufacturer pricing rules prevent us from advertising our discount — no account or email required to see it.
LTL Delivery
This product weighs 250 lb each and will be shipped via LTL carrier. A lift gate option will be added free of charge for your convenience.
-
Secure Payments
-
Easy Returns
-
Expert Advice
-
Fast Shipping
Product DescriptionThe MARATHON MOTORS MR836 is a three-phase electric motor suitable for various industrial tasks. This motor is built with a cast iron frame which ensures durability. The motor operates at a power output of twenty horsepower (15 kW) and a rotational speed of three thousand six hundred rpm. It is constructed with a Totally Enclosed Fan Cooled enclosure, making it ideal for demanding environments.
- Three-phase TEFC IEC motor.
- Cast iron frame construction.
- Inverter Rated Insulation System (IRIS).
Product Highlights
This motor is designed to withstand tough applications while maintaining high performance.Product Information
Standard Information
-
Power: 20 hp (15 kW)
-
Speed: 3600 rpm
Technical Specifications
-
Current: 45.5/22.8 amps
-
Voltage: 230/460 volts
-
Frame: IEC 160MD
-
Shaft Dimensions: 42 mm x 110 mm
-
Enclosure: TEFC-IP55 (weatherproof)
-
Conduit Box Location: F3 (top)
-
Insulation System: Inverter Rated Insulation System (IRIS)
-
Service Factor: 1.15
-
Insulation Class: Class F
-
Construction: Cast Iron Frame
-
Certifications: UL Listed, CSA Certified
-
Mounting Type: Rigid Base B3/B5 D-Flange
-
Windings: 12-lead Delta for line Wye-Delta starts
-
Seals: Oil seals at drive end and non-drive end
-
Shaft: Drilled and tapped
- Three-phase TEFC IEC motor.
- Cast iron frame construction.
- Inverter Rated Insulation System (IRIS).
Product Highlights
This motor is designed to withstand tough applications while maintaining high performance.Product Information
Standard Information
- Power: 20 hp (15 kW)
- Speed: 3600 rpm
Technical Specifications
- Current: 45.5/22.8 amps
- Voltage: 230/460 volts
- Frame: IEC 160MD
- Shaft Dimensions: 42 mm x 110 mm
- Enclosure: TEFC-IP55 (weatherproof)
- Conduit Box Location: F3 (top)
- Insulation System: Inverter Rated Insulation System (IRIS)
- Service Factor: 1.15
- Insulation Class: Class F
- Construction: Cast Iron Frame
- Certifications: UL Listed, CSA Certified
- Mounting Type: Rigid Base B3/B5 D-Flange
- Windings: 12-lead Delta for line Wye-Delta starts
- Seals: Oil seals at drive end and non-drive end
- Shaft: Drilled and tapped
