Marathon Motors MK646A General Purpose Motor 1 1/2 hp 1800 RPM NEMA 56HC

Product Description

The Marathon Motors MK646A is a three-phase general purpose motor that provides reliable performance. This unit delivers one and a half horsepower at eighteen hundred revolutions per minute. It is equipped with a NEMA 56HC frame and features a C-face mounting for easy installation.

• 1 1/2 hp, 1800 RPM
• NEMA 56HC frame with C-face mounting
• Operates at 230/460 Volts, 4.6/2.3 amps, 60Hz

Product Highlights

This motor is suitable for various applications where three-phase power is available. The design ensures efficient operation, making it ideal for many industrial environments.

Product Information

Standard Information

• Brand: Marathon Motors
• MPN: MK646A

Technical Specifications

• Horsepower: 1 1/2 hp
• RPM: 1800
• Amperage: 4.6/2.3 amps
• Voltage: 230/460 Volts
• Frequency: 60Hz
• Frame Type: NEMA 56HC
• Mounting Type: C-face
• Keyed Shaft: 5/8 inch Diameter x 1 7/8 inch
• Service Factor: 1.15
• Overload Protection: None
• Base Type: Rigid
• Rotation: Reversible
• Bearing Type: Ball Bearings
• Insulation Class: Class B
• Warranty: 1 Year Manufacturer Warranty
