Marathon Motors MD115 General Purpose Motor

Product Description

The Marathon Motors MD115 is a general-purpose motor designed for a variety of applications. This single-phase motor uses capacitor start and capacitor run technology, making it suitable for continuous duty. It features an open drip-proof enclosure and a sturdy rolled steel frame, ensuring durability in various environments. With automatic thermal protection, it provides added safety in operation. The motor can be mounted resiliently and includes ball bearings for smooth operation.

• Electrical type: Capacitor start/capacitor run
• Enclosure type: Open drip proof (ODP)
• Reversible rotation: Yes

Product Highlights

This motor is suitable for many applications, including HVAC systems and water pumps.

Product Information

Standard Information

• Brand: Marathon
• MPN: MD115

Technical Specifications

• Horsepower: 1 ½ hp
• Speed: 3450 RPM
• Voltage: 115/208-230 Volts
• Frequency: 60 Hz
• Load Amps: 13.4/7.4-6.7
• Phase: Single
• Frame Size: 56
• Enclosure: Open Drip Proof
• Service Factor: 1.15
• Dimensions: 11.72 inches
• Shaft: Keyed Shaft 1 7/8 x 5/8 diameter
