MARATHON MOTORS MA100 Condenser Motor 1/3 HP 850 RPM

Product Description

The MARATHON MOTORS MA100 is a three-phase condenser motor. It operates at 208-230/460 Volts and runs at 850 RPM with a single speed setting. The motor has a 56Y frame size and a shaft dimension of five-eighths by five inches, equipped with a key and flat. Its design includes an open enclosure and ball bearings. A voltage change device is included for adjusting power requirements.

• Three-phase design for efficiency.
• Operates smoothly at 850 RPM.
• Includes a voltage change device for easy adjustments.

Product Highlights

This motor is ideal for various cooling applications and enhances system reliability.

Product Information

Standard Information

• Brand: Marathon Motors
• Phase: 3 Phase

Technical Specifications

• Horsepower: 1/3 HP
• RPM: 850
• Speed: 1 Speed
• Voltage: 208-230/460 Volts
• Current: 2.3-2.5-1.25 Amps
• Frame Size: 56Y Frame
• Shaft Dimension: 5/8 x 5 with Key & Flat
• Mounting Type: Belly Band Mount
• Enclosure: Open
• Bearing Type: Ball Bearing
• Notes: Voltage Change Device for quick adjustments
