Marathon Motors M1125080.00 AC Right Angle Gearmotor Motor 3/50 HP

Product Description

The Marathon Motors M1125080.00 is an AC Right Angle Gearmotor Motor designed for high efficiency and durability in various applications. With a rated power of three-fiftieths horsepower, this gearmotor operates at one hundred fifteen volts and draws a maximum of zero point ninety or zero point forty-five amps. It offers a rotational speed of twenty-eight revolutions per minute and operates at sixty hertz frequency. This motor features a totally enclosed non-ventilated (TENV) design that meets robust industrial standards.

• Permanent split capacitor design
• Worm-type right-angle gearing with hardened steel components
• Precision machined aluminum gear housing

Product Highlights

This gearmotor is suitable for demanding environments and provides reliable performance. The lubrication system is permanent, ensuring long operational life, and all components are designed for quiet operation. The output shaft's configuration can be easily changed from left to right, allowing flexibility in installation.

Product Information

Standard Information

• Brand: Marathon Motors
• Model Number: CM31P17NZ19A

Technical Specifications

• Power: 3/50 HP
• Voltage: 115 Volts
• Amperage: 0.90/0.45 Amps
• Phase: 1 Phase
• RPM: 28
• Frequency: 60 Hz
• Enclosure Type: TENV
• Frame Size: 31
