Marathon Motors A099250.00 1-Phase Farm Fan Motor

Product Description

The Marathon Motors A099250.00 is a 1-Phase farm fan motor suitable for various applications. It operates at 1/2 horsepower and runs at 900 RPM. This motor supports both 115 and 230V power sources at 60 Hz. Its NEMA 48YZ frame makes it easy to install and attach directly to a fan.

• Designed for direct attachment to a fan
• Features automatic overload protection
• Totally Enclosed Air Over (TEAO) enclosure

Product Highlights

This motor is reversible and includes ball bearings for smooth operation. It also requires placement in the airstream during use. A wiring diagram is conveniently located on the nameplate for easy reference.

Product Information

Standard Information

• UPC: 691720053881

Technical Specifications

• Horsepower: 1/2 hp
• RPM: 900
• Voltage: 115/230V
• Frame Size: 48YZ
• Enclosure Type: TEAO
• Phase: 1-Phase
• Current: 6.0/3.0 amps
• Frequency: 60 Hz
• Shaft Diameter: 5/8 inches
• Shaft Length: 2 5/8 inches
• Service Factor: 1.15
• Overload Protection: Auto
• Bearing Type: Ball Bearings
• Insulation Class: B
• Reversible: Yes
