Marathon Electric R237M2B 5 HP Pool Pump Motor

Product Description

The Marathon Electric R237M2B is a five horsepower pool pump motor designed for continuous duty applications. It operates on voltages of one hundred ninety, three hundred eighty, two hundred twenty, or four hundred forty volts, and can work with both fifty and sixty hertz electrical systems. This motor has multiple current ratings of fourteen point four, seven point six, thirteen, or six point five amps, making it adaptable for various operational needs.

• Drip-proof enclosure ensures reliable performance.
• Reversible rotation for flexible installation.
• Compatible with Purex Hydrotech pumps.

Product Highlights

This motor is equipped with Class F insulation, allowing operation in temperatures up to forty degrees Celsius. It is also designed for inverter duty applications with a variable torque ratio of ten to one.

Product Information

Standard Information

• Brand: Marathon Electric
• Catalog Number: R237M2B

Technical Specifications

• HP: 5
• Volts: 190/380/220/440 V
• Frequency: 50/60 Hz
• Amps: 14.4/7.6/13/6.5 A
• RPM: 3500
• Phase: 3
• Enclosure Type: Drip Proof
• Rotation: Reversible
• Shaft Diameter: 1 inch
• Shaft Type: Keyed
• Frame Type: 182TDZ
• Weight: 40 lbs
• Country of Origin: Mexico
