Marathon Electric Motors Y280 Variable Speed Motor 0.50 HP 3 Phase 230/460 V

Product Description

The Marathon Electric Motors Y280 is a variable speed motor with a power rating of 0.50 HP. It operates at three phases with a voltage of 230/460 V and reaches a speed of 1800 RPM. The motor features a 56C frame design and is classified as Totally Enclosed Non Ventilated (TENV), making it suitable for various applications.

• Integrated Dynapar HS20 1024 ppr encoder
• Class F insulation with CR200 corona resistant magnet wire
• Field reversible to F2

Product Highlights

This motor provides constant torque operation from zero to base speed on vector drive systems. It is suitable for applications that require high reliability and efficiency.

Product Information

Standard Information

• Manufacturer: Marathon Electric Motors
• Power Factor: 72

Technical Specifications

• Power Rating (HP): 0.50
• Voltage: 230/460
• Speed: 1725 RPM
• Current: 1.6/0.80 Amps
• Enclosure Type: Totally Enclosed Non Ventilated
• Efficiency: 80%
• Frame Size: 56
• Number of Poles: 4
