Marathon Electric Motors SY066 AC Motor 3 HP

Product Description

The Marathon Electric Motors SY066 is an AC motor designed for general purpose use. This motor provides a powerful three horsepower output and operates at a speed of 1800 revolutions per minute. The motor runs on a three-phase power system with a voltage rating of 230/460 volts. It includes a bolt-on base mount and features a totally enclosed fan cooled (TEFC) design for durability and efficient cooling.

• General purpose AC motor for versatile applications
• Three horsepower and operates at 1800 RPM
• Reversible rotation with a voltage rating of 230/460 volts

Product Highlights

This motor is suitable for a variety of applications in HVAC, industrial settings, and manufacturing processes.

Product Information

Standard Information

• Brand: Marathon Electric Motors
• MPN: SY066

Technical Specifications

• Frame Size: 182TC
• Poles: 6
• Service Factor: 1
• Phase: Three Phase
• Enclosure Type: TEFC
• Voltage Rating: 230/460
• Full Load Amps: 6.6/3.3
• Drive End Bearing: 6207
• Open End Bearing: 6205
• Rotation: Reversible
• Hz: 90
• Insulation Class: F
• Weight: 0.0 LB
• EAN/UPC: 722856061973
