Marathon Electric Motors SY036 AC Motor 3 HP 182TC Frame

Product Description

The Marathon Electric Motors SY036 is a three-phase AC motor designed for general purpose applications. This powerful motor delivers three horsepower and operates at a speed of twelve hundred RPM. The SY036 is built with a rigid base mount and a totally enclosed fan cooled (TEFC) design ensuring reliable operation in various environments.

• Power: 3 hp
• Voltage: 230/460
• Frame: 182TC

Product Highlights

The SY036 is suitable for a variety of industrial applications, providing efficient performance and durability.

Product Information

Standard Information

• Manufacturer: Marathon Electric Motors
• Part Number: SY036

Technical Specifications

• Enclosure Designation: Totally Enclosed Fan Cooled
• Mounting: Rigid Base
• Insulation Class: H
• Frequency: 60 Hz
• Frame Size: 182TC
• Rotation: Reversible
• Full Load Amps: 7/3.5
• Voltage Rating: 230/460
• Poles: 6
• Service Factor: 1
• Drive End Bearing: 6207
• Open End Bearing: 6205
• Motor Application: General Purpose
• EAN or UPC: 722856061966
