Marathon Electric Motors LM33484 AC Motor 5 hp 1760 rpm 230/460

Product Description

The Marathon Electric Motors LM33484 is a three-phase AC motor designed for general purpose applications. This motor has a power output of five horsepower and operates at a speed of seventeen hundred sixty revolutions per minute. The voltage rating of this unit is two hundred thirty to four hundred sixty volts, making it suitable for a variety of industrial settings.

• General Purpose Motor Application
• Rigid Base Mount
• TEFC Enclosure for better protection

Product Highlights

This motor is ideal for those requiring reliable operation and efficiency. Its design features a totally enclosed fan-cooled enclosure to shield the internal components from dust and moisture.

Product Information

Standard Information

• Brand: Marathon Electric Motors
• MPN: LM33484

Technical Specifications

• RPM: 1760 rpm
• Phase: Three Phase
• Enclosure Designation: Totally Enclosed Fan Cooled
• Hz: 60
• Insulation: F
• Enclosure: TEFC
• Drive End Bearing: 6206
• Rotation: Reversible
• Motor Application: General Purpose
• Open End Bearing: 6205
• Frame Material: Aluminum
• Efficiency Group: 89.5 %
• Voltage Rating: 230/460
• Full Load Amps: 12.6/6.3
• Mounting: Rigid Base
• Poles: 4
• Frame: 184TC
• Weight: 104.0 LB
• EAN or UPC: 691720060810
