Marathon Electric Motors G572 General Purpose Motor 0.75 HP 1 Phase 56C Frame

Product Description

The Marathon Electric Motors G572 is a 0.75 horsepower general purpose motor designed for single-phase applications. It operates at 1800 RPM and is compatible with 115/208-230 voltage. The motor features a 56C frame, ensuring suitability for various mounting types.

• Capacitor start design for high starting torque.
• Durable construction with heavy gauge steel.
• Compatible with optional accessories for enhanced functionality.

Product Highlights

The G572 motor is equipped with double sealed ball bearings and a rigid base for stable operation. It is suitable for both horizontal and vertical mounting.

Product Information

Standard Information

• Brand: Marathon Electric Motors
• Part Number: G572

Technical Specifications

• Horsepower: 0.75 HP
• Voltage: 115/208-230 V
• Speed: 1725 RPM
• Frame Size: 56C
• Mounting Type: Rigid Base
• Service Factor: 1.15
• Efficiency: 70.5%
• Country of Origin: Mexico
