Marathon Electric Motors 140816.00 AC Motor 10 hp 230 Voltage Rating

Product Description

The Marathon Electric Motors 140816.00 is a robust AC motor designed for specific applications such as tobacco barns. This motor operates at ten horsepower and features a speed of one thousand seven hundred thirty revolutions per minute. It runs on a single-phase power supply at two hundred thirty volts.

• Ten horsepower output
• Operates at one thousand seven hundred thirty RPM
• Designed for single-phase systems

Product Highlights

This AC motor is built for durability and efficiency, making it suitable for demanding environments.

Product Information

Standard Information

• Brand: Marathon Electric Motors
• Part Number: 113079993

Technical Specifications

• Enclosure Designation: Drip Proof Air Over
• Poles: 4
• Rotation: Selective CCW
• Voltage Rating: 230
• Frame: 215TVZ
• Phase: Single Phase
• Drive End Bearing: 6307
• Hz: 60
• RPM: 1730
• Mounting: Rigid Base
• Motor Application: Tobacco Barn
• Frame Material: Rolled Steel
• Efficiency Group: 82.5%
• Full Load Amps: 44
• Enclosure: DPAO
• Insulation: H
• Open End Bearing: 6206
• Weight: 150.0 LB
• EAN or UPC: 691720053669
