Mansfield 310614300 Barrett Tank 1.28 GPF (Tank Only)

Product Description

The Mansfield 310614300 is a replacement vitreous china toilet tank (model 3106) designed for 1.28 gallons-per-flush systems. This tank-only component measures 16.75 x 19 x 8.75 inches (aggregated) and weighs 42.0 lbs. It stores and releases water for gravity-fed flushing and is configured for a 3-inch flush valve. Typical uses include repair and part replacement for compatible toilet bowls.

• Vitreous china construction for the replacement tank (model 3106)
• 1.28 gallons-per-flush flow rate with 3-inch gravity flush valve
• Aggregated product dimensions 16.75 x 19 x 8.75 in; unit weight 42.0 lbs; tank-only configuration

Product Highlights

Replacement vitreous china toilet tank model 3106, 1.28 GPF, tank-only

Product Information

Standard Information

• Brand: MANSFIELD
• Manufacturer Part Number: 310614300
• Country of Origin: Colombia

Technical Specifications

• Brand: MANSFIELD
• Manufacturer Part Number: 310614300
• Model Number: 3106
• Product Name: Tank 3106 Barrett
• Configuration: Tank Only
• Material: Vitreous China
• Flow Rate: 1.28 gallons-per-flush
• Flush Valve Size: 3 in
• Flush Type: Gravity Flush
• Product Height: 16.75 in
• Product Width: 19 in
• Product Depth: 8.75 in
• Aggregated Product Dimensions: 16.75 x 19 x 8.75 in
• Carton Dimensions: 19.5 x 11.2 x 12 in
• Product Weight: 42.0 lbs
• Finish: Biscuit
• Trip Lever Placement: Left
• Certifications: UPC, ASME, CSA
• ASME Code: A112.19.2
• CSA Code: B45.1
• UPC: 46587195456
• Country Of Origin: Colombia
• Made In USA: No
• ADA Compliant: No
• High Efficiency: No
