Mansfield 232-4-wh Verona Oval Pedestal Lavatory White

Product Description

The MANSFIELD 232-4-wh is a vitreous china oval pedestal lavatory from the Verona Series 230 collection. Designed for pedestal-mount installation, this sink basin pairs with a compatible pedestal base and accepts standard 3-hole faucet sets with 4-inch faucet hole spacing. The lavatory features an integral rear overflow, providing a built-in safety drain path. Overall dimensions measure 18-5/16 inches wide by 17-7/16 inches deep, with a bowl size of 15 inches wide by 10-1/2 inches deep. The vitreous china construction delivers a durable, non-porous surface. The finish is White. This unit is intended for licensed plumbers performing bathroom lavatory installations in residential applications.

The 232-4-wh is suited for residential bathroom installations where a classic oval pedestal lavatory is specified. The pedestal-mount design requires a compatible pedestal base (sold separately) and floor or wall rough-in plumbing sized to align with pedestal mounting. Three faucet holes accommodate a widespread or centerset faucet configuration at 4-inch spacing. This lavatory is part of the Verona collection and is available in White, making it a straightforward fit for standard bathroom remodels or new construction where vitreous china fixtures are called for.

Key Features

• Vitreous china construction for a dense, non-porous, and easy-to-clean surface
• Integral rear overflow prevents countertop flooding and meets standard plumbing code requirements
• Oval basin shape with interior bowl dimensions of 15 inches wide by 10-1/2 inches deep
• 4-inch faucet hole spacing with 3 pre-drilled faucet holes for widespread faucet compatibility
• Overall footprint of 18-5/16 inches wide by 17-7/16 inches deep suits compact bathroom layouts
• Part of the Verona Series 230 collection in a White finish

Compatibility

Designed as an OEM-style pedestal lavatory basin for use with compatible pedestal bases and 3-hole widespread or centerset faucets with 4-inch center-to-center spacing. Specific pedestal base compatibility should be confirmed with MANSFIELD or the project specification sheet prior to installation.

Installation Notes

Installation should be performed by a licensed plumber in accordance with applicable local plumbing codes and the International Plumbing Code (IPC). Shut off the water supply and drain all lines before beginning work. The pedestal base and floor mounting hardware are not included with this lavatory basin and must be sourced separately. Do not overtighten faucet mounting nuts against the vitreous china surface, as cracking can result.

Technical Specifications

• Series: 230 Verona
• Shape: Oval
• Material: Vitreous China
• Finish/Color: White
• Mounting Type: Pedestal
• Overall Dimensions: 18-5/16 inches W x 17-7/16 inches D x 31-11/16 inches H
• Bowl Size: 15 inches W x 10-1/2 inches D
• Number of Faucet Holes: 3
• Faucet Hole Spacing: 4 inches
• Integral Overflow: Yes, Rear
• ADA Compliant: No

Standard Information

• Brand: MANSFIELD
• Manufacturer Part Number: 232-4-wh
