Magnaloy M370N8 Flexible Coupling Insert

Product Description

The Magnaloy M370N8 is a flexible coupling insert designed for various horsepower and RPM needs. It allows users to customize their selection based on shaft diameter and keyway size, which can be ordered separately. The coupling is made from lightweight magnesium, leading to significant weight reduction compared to traditional materials.

• Lightweight construction enhances performance
• Compatible with multiple horsepower and RPM requirements
• Designed for optimal load capacity and resilience

Product Highlights

Lightweight and durable, suitable for a range of applications in the field.

Product Information

Standard Information

• Brand: Magnaloy Coupling Co.
• Part #: 100443215

Technical Specifications

• HP @ RPM: 1.12 hp @ 100 rpm, 13.5 hp @ 1200 rpm, 20.2 hp @ 1800 rpm
• Hardness: 80
• Material: Neoprene
• Torque Rating: 701.4 in lb
• Temperature Range [Min]: -30 °F
• Coupling Size: 300
• Color: Gold
• Temperature Range [Max]: 250 °F
• Insert Style: One Piece
• No. of Legs: 3
• Weight: 1.0 LB
