Magnaloy Coupling Co. M400R Flexible Coupling Hub Each

Product Description

The Magnaloy Coupling Co. M400R is a flexible coupling hub designed for use in various applications, primarily to connect electric motor shafts to hydraulic pumps or gearboxes. This product ensures proper alignment and energy transfer between components.

• Lightweight magnesium construction provides superior strength compared to traditional materials.
• Easy installation and handling for quick setup in mechanical systems.
• Corrosion resistance prevents wear and extends the lifespan of the coupling.

Product Highlights

The M400R offers reliable performance with reduced load on bearings, shafts, and pumps, making it ideal for multiple industrial applications.

Product Information

Standard Information

• Brand: Magnaloy Coupling Co.
• MPN: M400R

Technical Specifications

• Lock Type: Setscrew
• Hub Diameter: 3.05 inches
• Coupling Size: 400
• Outside Diameter: 3.98 inches
• Length Through Bore: 1.52 inches
• Max Bore Diameter: 1 7/8 inches
• Input Bore Range: 0 to 1 7/8 inches
• Weight: 1.165 lbs
