Magnaloy Coupling Co. M324872D Horizontal Pump/Motor Mount Adapter

Product Description

The Magnaloy Coupling Co. M324872D is a horizontal pump/motor mount adapter designed for efficient alignment and secure mounting. It is compatible with SAE D pump flanges and various motor frames.

• Horizontal pump/motor mount adapter
• Constructed from aluminum for durability
• Designed for use with motor frames 324TC/TSC-405TC/TSC and 324UC/USC-405UC/USC

Product Highlights

This adapter is essential for proper alignment in pumping systems, ensuring optimized performance and longevity. Its aluminum construction provides lightweight durability.

Product Information

Standard Information

• Part Number: M324872D
• Brand: Magnaloy Coupling Co.

Technical Specifications

• Pump Flange: SAE D
• Mounting Type: Horizontal
• Axial Clearance: 7 7/8 inches
• Motor Frame: 324TC/TSC-405TC/TSC, 324UC/USC-405UC/USC
• Motor Mount Holes: 4
• Pump Flange Type: SAE
• Radial Clearance: 7.74 inches
• Material: Aluminum
• Pump/Motor Mount Length: 8 3/4 inches
• Weight: 17.0 lbs
