Magnaloy Coupling Co. M182702C Horizontal Pump/Motor Mount Adapter

Product Description

The Magnaloy Coupling Co. M182702C is a Horizontal Pump/Motor Mount Adapter designed to provide a secure connection between SAE C pump flanges and motor frames. This adapter is compatible with motor frames ranging from 182TC to 256TC and 213UC to 256UC, ensuring versatile applications in various setups.

• Horizontal pump/motor mount with a length of seven inches
• Constructed from durable aluminum
• Features four motor mount holes for easy installation

Product Highlights

This adapter is ideal for mounting pumps and motors securely, allowing for efficient operation in industrial settings.

Product Information

Standard Information

• Brand: Magnaloy Coupling Co.
• Part Number: M182702C

Technical Specifications

• Pump Flange Type: SAE
• Pump/Motor Mount Length: 7 in
• Material: Aluminum
• Mounting Type: Horizontal
• Pump Flange: SAE C
• Motor Mount Holes: 4
• Motor Frame Compatibility: 182TC-256TC, 213UC-256UC
• Axial Clearance: 6 1/4 in
• Radial Clearance: 5 in
• Weight: 6.0 LB
