Magnaloy Coupling Co. M056424F Horizontal Pump/Motor Mount Adapter

Product Description

The Magnaloy Coupling Co. M056424F is a Horizontal Pump/Motor Mount Adapter designed for efficient performance. This adapter is made from aluminum to ensure durability and strength. It is suitable for use with USA4F17 pump flanges, accommodating motor frames including 56C, 143TC, 145TC, 182UC, and 184UC.

• Compatible with USA4F17 pump flanges
• Aluminum construction
• Supports horizontal and vertical mounting

Product Highlights

This product is designed to facilitate the connection between electric motors and pumps. The robust design helps to maintain alignment and reduce wear.

Product Information

Standard Information

• Brand: Magnaloy Coupling Co.
• Part Number: 100439560

Technical Specifications

• Pump Flange: USA4F17
• Material: Aluminum
• Motor Frame: 56C, 143TC/145TC, 182UC/184UC
• Pump Flange Type: SAE
• Mounting Type: Horizontal, Vertical
• Axial Clearance: 3.56 inches
• Radial Clearance: 4.15 inches
• Motor Mount Holes: 4
• Pump/Motor Mount Length: 4.25 inches
• Weight: 3.0 LB
