Magnaloy Coupling Co. M056422A Horizontal Pump/Motor Mount Adapter

Product Description

The Magnaloy Coupling Co. M056422A is a horizontal pump/motor mount adapter designed for aligning hydraulic pumps with electric motors. Constructed from durable aluminum, this component supports SAE A pump flanges and is compatible with motor frames 56C, 143TC, 145TC, and 182UC, ensuring reliable performance in various applications.

• Includes both SAE two-bolt and SAE four-bolt mounting options
• Constructed from lightweight aluminum for easy installation
• Supports horizontal and some vertical mounting configurations

Product Highlights

This adapter is essential for maintaining alignment between pumps and motors, enhancing efficiency in system operations.

Product Information

Standard Information

• Brand: Magnaloy Coupling Co.
• Part Number: 100439556

Technical Specifications

• Motor Frame: 56C, 143TC/145TC, 182UC/184UC
• Axial Clearance: 3.56 inches
• Radial Clearance: 4.15 inches
• Motor Mount Holes: 4
• Pump/Motor Mount Length: 4.25 inches
• Mounting Type: Horizontal, Vertical
• Pump Flange Type: SAE
• Pump Flange: SAE A
• Material: Aluminum
• Weight: 2.0 lbs
