MAGNAFLUX 01-1725-78 Aqua-Glo 14A Magnetic Particle Suspension

Product Description

MAGNAFLUX 01-1725-78 Aqua-Glo is a water-based magnetic particle suspension. It is designed to detect fine discontinuities in hard-to-reach areas. The product offers advantages of a water bath while remaining portable for easy use. This non-flammable formula features high-sensitivity fluorescent magnetic particles suitable for field testing.

• High-sensitivity detection with 14A particles
• Finds smaller indications in critical applications
• Optimized particle size reduces clumping

Product Highlights

This product is useful in identifying cracks, seams, inclusions, and other defects. It is suitable for testing forgings and welds in various applications.

Product Information

Standard Information

• Compliance Standards: AMS 3044, ASTM E709, ASTM E1444, ASME, MIL-STD-2132, MIL-STD-271, NAVSEA 250-1500-1, NAVSEA T9074-AS-GIB-010/271
• NDT Type: Fluorescent Magnetic Particle Testing

Technical Specifications

• Vehicle: Water
• Required Equipment: Magnetizing device, UV light source
• Ideal Applications: Field testing, in-service inspections, critical applications
• Defect Examples: Fatigue cracks, grinding cracks, inclusions, weld defects
• Appearance: Oily liquid with fine particles
• Color in UV Light: Fluorescent yellow-green
• Mean Particle Size: 6 microns
• Odor: Minimal
• Flash Point: Greater than 200 °F
• Usage Temperature: 42 to 120 °F
• Storage Temperature: 50 to 86 °F
• Settling Volume: 0.10 - 0.40 mL
