Macomb Group B2022ZN 8 IN Pipe Strut Clamp Plated

Product Description

The MACOMB GROUP B2022ZN Strut Clamp, part of the Series B2000, is designed for 8 IN pipes. Constructed from 11 GA low carbon steel conforming to ASTM A1011HSLA Grade 50, it features an electro-zinc plated finish according to ASTM B633 SC3 Type III. It supports a vertical maximum load of 1000 LB, a transverse maximum load of 250 LB, and a longitudinal maximum load of 200 LB.

• Nominal size: 8 IN Pipe
• Material: 11 GA Low Carbon Steel
• Finish: Electro-Zinc Plated

Product Highlights

The MACOMB GROUP B2022ZN strut clamp provides robust support for pipe systems, with a focus on durability and corrosion resistance.

Product Information

Standard Information

• Brand: MACOMB GROUP
• Manufacturer Part Number: B2022ZN

Technical Specifications

• Series/Model: Series B2000
• Nominal Size: 8 IN Pipe
• Vertical Maximum Load: 1000 LB
• Transverse Maximum Load: 250 LB
• Longitudinal Maximum Load: 200 LB
• Material: 11 GA Low Carbon Steel
• Material Standard: ASTM A1011HSLA Grade 50
• Finish: Electro-Zinc Plated
• Finish Standard: ASTM B633 SC3 Type III
