Macomb Group 25300 1-1/2 2000 Fs Thrd 45 Ell

Product Description

The MACOMB GROUP 25300 is a 45 DEG Elbow with Class 2000 Pressure Class and a Nominal Size of 1-1/2 IN. Constructed from Forged Steel with FNPT Connection Type and SCH 80 Schedule. Compliant with Industry Standards ASME B16.11 and ASME B1.20.1, with an Outside Diameter of 2-1/2 IN and Other Physical Dimension: 1-3/8 IN Center To End.

• 45 DEG Elbow
• Class 2000 Pressure Class
• Nominal Size: 1-1/2 IN

Product Highlights

The MACOMB GROUP 25300 is a durable and reliable 45 degree elbow suitable for various industrial applications.

Product Information

Standard Information

• Brand: MACOMB GROUP
• Manufacturer Part Number: 25300
• Country of Origin: Domestic

Technical Specifications

• Pressure Class: Class 2000
• Nominal Size: 1-1/2 IN
• Connection Type: FNPT
• Schedule: SCH 80
• Material: Forged Steel
• Material Standard: ASTM A105
• Outside Diameter: 2-1/2 IN
• Industry Standards: ASME B16.11, ASME B1.20.1
• Center To End Dimension: 1-3/8 IN
